- The hardware system of the device includes a quad-core ARM Cortex-A55 CPU running at 2 GHz, 1 GB of LDDR4x RAM, and 1 GB of NAND Flash memory.
- It supports 5G NR SA & NSA/4G LTE/WCDMA cellular networks with various frequencies.
- The device has multiple Ethernet interfaces, including 1 WAN and 4 LAN ports, with support for full or half duplex mode.
- Optional features include Wi-Fi connectivity, GNSS (GPS/GLONASS/Beidou/Galileo/QZSS), serial interfaces (RS232 and RS485), DI/DO (dry contact and wet contact), USB 3.0, reset button, and LED indicators.
- The device supports various network protocols, VPN (IPsec, OpenVPN), security features (access control, DMZ, port forwarding), and management options (web, DeviceHub, MilesightVPN).
- It can be powered by a 9-48 VDC input or 5V, 3A through a Type-C port, and has different power consumption levels depending on the usage.
- The device has an IP30 ingress protection rating, a metal housing, and can be installed on a desktop, wall, or DIN rail.
- It operates in a wide temperature range from -30Β°C to +60Β°C (-22β to +140β) and has Ethernet isolation of 1.5 kV RMS.
Hardware System
| CPU |
Quad-core ARM Cortex-A55οΌ2 GHz |
| Memory |
1 GB LDDR4x RAM and 1 GB NAND Flash |
| Extendable Storage |
1 Γ M.2 NVMe SSD Interface |
Cellular Interface
| Network |
5G NR SA & NSA/4G LTE/WCDMA |
| Frequency |
5G Sub-6: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78 |
| LTE FDD: B1/B3/B5/B7/B8/B20/B28/B32 |
| LTE TDD: B38/B40/B41/B42/B43 |
| WCDMA: B1/B5/B8 |
| Antenna |
4 Γ 50 Ξ© SMA Connectors (Center PIN: SMA Female) |
| SIM Slot |
2οΌMini SIM-2FFοΌ |
Ethernet Interface
| Numbers |
5 Γ 10/100/1000 Mbps |
| Property |
1 Γ WAN +4 Γ LAN |
| Mode |
Full or Half Duplex (Auto-Sensing) |
| PoE |
4 Γ 802.3 af/at PoE PSE on LAN Ports (Optional) |
Wi-Fi Interface (Optional)
| Antenna |
4 Γ 50 Ξ© SMA Connectors (Center PIN: RP-SMA Female) |
| Standards |
IEEE 802.11b/g/n/ax 2 x 2 MIMO, 2.4 GHz |
| IEEE 802.11a/n/ac/ax 2 x 2 MIMO, 5 GHz |
| Max Bit Rate |
2.4 GHz: 600 Mbps, 5 GHz: 1200 Mbps |
| Modes |
AP Mode |
| Security |
WEP/WPA/WPA2 authentication, WEP/TKIP/AES encryption |
GNSS
| Antenna |
1 Γ 50 Ξ© SMA Connector (Center PIN: SMA Female) |
| Technology |
GPS/GLONASS/Beidou/Galileo/QZSS |
| Protocol |
NMEA 0183 |
Serial Interface
| Numbers |
1 Γ RS232 + 1 Γ RS485 |
| Connector |
3.5 mm Terminal Block |
| Baud Rate |
300bps to 230400bps |
DI/DO
| Numbers |
1 Γ DI (Dry Contact) + 1 Γ DO (Wet Contact)οΌ Galvanic Isolation |
| Connector |
3.5 mm Terminal Block |
| Maximum V/A |
0.3A@30VDC (DO) |
Others
| USB |
1 Γ USB 3.0 (Type-C) for Power Supply, Network Supply and Debug |
| Reset Button |
1 Γ RESET |
| LED Indicators |
1 Γ SYSTEMοΌ1 Γ SIM1οΌ1 Γ SIM2 |
| Built-in |
Watchdog, Timer |
Software
| Network Protocols |
IPv4/IPv6, TCP, UDP, DHCP, HTTP, HTTPS, ARP, NTP, DNS, ARP, SSH, etc. |
| VPN |
IPsec, OpenVPN |
| Security |
Access Control, DMZ, Port Forwarding, SYN-Flood Protection, Filtering (IP & MAC & Domain) |
| Management |
Web, DeviceHub, MilesightVPN |
| Multilevel Authority |
Multiple Levels of User Authority |
| Reliability |
WAN Failover, Dual SIM Backup |
| Serial Port |
Transparent (TCP Client/Server, UDP), Modbus Master, Modbus Gateway (Modbus RTU to Modbus TCP) |
Power Supply and Consumption
| Power Connector |
2-pin 3.5 mm Terminal Block |
| Power Input |
1. 9-48 VDC, with Surge-Protection and Reverse Polarity Protection |
| 2. 5V, 3A by Type-C Port |
| Power Consumption |
Without Wi-Fi: Typical 2.8 W, Max 5.5 W |
| (In Non-PoE mode) |
With Wi-Fi: Typical 7 W, Max 13.7 W |
Physical Characteristics
| Ingress Protection |
IP30 |
| Housing |
Metal |
| Dimension |
135 x 115 x 36.4 mm (5.31 x 4.53 x 1.43 in) |
| Installation |
Desktop, Wall or DIN Rail Mounting |
Environmental
| Operating Temperature |
-30Β°C to +60Β°C (-22β to +140β) |
| Storage Temperature |
-40Β°C to +85Β°C (-40β to +185β) |
| Ethernet Isolation |
1.5 kV RMS |
| Relative Humidity |
0% to 95% (Non-condensing) at 25Β°C/77β |
