WS523-915M - Portable Socket (PN: 10A-US / 10A-AU/ 13A-UK / 15A-US / 16A-EU)
The Smart Portable Socket from Milesight is a remote-controlled device that allows users to easily turn on/off electrical appliances using their mobile phones. It also offers features such as time-based scheduling, electricity usage tracking, and overload protection. The socket uses LoRaWAN technology for data transmission and is compatible with standard LoRaWAN gateways and network servers. The device can be managed using the Milesight IoT Cloud and comes with an Android and iOS app for easy control. It also supports NFC configuration for quick setup. The socket is available in different plug types and has a maximum load capacity of 10A~16A.
Specifications
| Wireless Transmission | |
|---|---|
| Technology | LoRaWAN® |
| Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 |
| Tx Power | 16 dBm (868 MHz)/22 dBm (915 MHz)/19 dBm (470 MHz) |
| Sensitivity | -137dBm |
| Mode | OTAA/ABP Class C |
| Electrical | |
| Socket & Plug Type | US/EU/AU/UK/CN, etc. |
| Operating Voltage | 100~250 VAC, 50~60 Hz |
| Max Load Capacity | 10 A~16 A (Optional), 250 VAC |
| Measurement | Voltage (VAC), Current (mA), Power Factor (%), Power (W), Power Consumption (kWh) |
| Measurement Accuracy | ±3 % |
| Software | |
| Configuration | Mobile App via NFC or Downlink |
| Power Control | Button or Remote Control |
| Advanced Features | Schedule Switch, Button Lock, Overcurrent Protection/Alarm, Multicast, Power Outage Alert |
| Others | |
| LED Indicator | 1 |
| Button | ON/OFF, Reset |
| Physical Characteristics | |
| Material | Polycarbonate |
| Color | White |
| Operating Temperature | -20°C to +60°C (-4℉ to +140℉) |
| Relative Humidity | 10% to 90% (non-condensing) |
| Dimensions | 110 × 62.3 × 34.6 mm (4.33 × 2.45 × 1.36 in) (Plug is not included) |
