VS121-P - AI Workplace Occupancy Sensor (High Ceiling Mount Version)
The Milesight AI Occupancy Sensor is a device that uses anonymous people counting data to provide insights on space utilization. It is applicable in various spaces such as workplaces and airports, and offers features like low power consumption, easy wireless deployment, and long-distance transmission. The sensor ensures privacy protection and high accuracy through embedded AI algorithms. It also offers features like people flow analysis, dwell time detection, and line crossing people counting. The sensor can be integrated with third-party analytics platforms and is suitable for multiple industries.
Key Points:
- Milesight AI Occupancy Sensor provides insights on space utilization through anonymous people counting data.
- The sensor is applicable in various spaces such as workplaces and airports.
- It offers features like low power consumption, easy wireless deployment, and long-distance transmission.
- The sensor ensures privacy protection and high accuracy through embedded AI algorithms.
- It offers features like people flow analysis, dwell time detection, and line crossing people counting.
- The sensor can be integrated with third-party analytics platforms and is suitable for multiple industries.
Specifications
| People Counting | |
|---|---|
| Field of View | Standard Version: 190 ° Horizontal, 112 ° Vertical High Ceiling Mount Version: 129.4 ° Horizontal, 68.4 ° Vertical |
| Recognition Range | Standard Version: a Radius of 5 Meters, At the Height of 3m High Ceiling Mount Version:18m × 7m, At the Height of 7m |
| Installation Height | Standard Version: 2.5m to 4m High Ceiling Mount Version: 5m to 7m |
| Recognition Rate | Region Counting: Up to 95% Line Crossing Counting: Up to 98% |
| Advanced Feature | Mapped Detection Region Customization, Filter U-Turns, Privacy Mask |
| LoRaWAN® Transmission | |
| Protocol | - |
| Frequency | - |
| Tx Power | - |
| Sensitivity | - |
| Mode | - |
| Ethernet Transmission | |
| Ethernet Port | 1 × RJ45 10/100 Mbps (PoE PD) |
| Network Protocol | HTTP, RTSP, NTP, SSH,etc. |
| Other Interfaces | |
| Wi-Fi | - |
| DI/DO | 1/1 |
| Serial Interface | 1 × RS485 |
| Button | 1 × Reset Button |
| LED Indicators | 1 × Status |
| Power Input | 2-pin 3.5 mm Terminal Block |
| Physical Characteristics | |
| Power Supply | 1. 5VDC / 2A by Terminal Block 2. 802.3af PoE |
| Power Consumption | 1. DC:3.5W 2. POE:4.5W |
| Operating Temperature | -5°C ~ +55°C |
| Storage Temperature | -20°C ~ +60°C |
| Relative Humidity | 0 ~ 95% (Non-condensing) |
| Color&Weight | White, 186g |
| Dimension | 85 × 85 × 30 mm (3.35 × 3.35 × 1.18 in) |
| Installation | Ceiling Mounting |
| Approvals | |
| Regulatory | CE, FCC, RoHS |
