AM103-915M - AM100 Series
The AM103/AM103L is a compact indoor air quality (IAQ) sensor that accurately detects CO2 concentration, humidity, and temperature.
Key points:
- The AM103/AM103L is designed to ensure healthy indoor environments by monitoring IAQ parameters.
- It features a traffic light status indicator and emoticon indication to provide visual cues about the air quality.
- The sensor has a hibernation mode to save power when not in use and a long battery life of 3 years for AM103 and 4 years for AM103L.
- The device can be wirelessly installed and has anti-theft protection.
- It is compatible with LoRaWAN technology for wireless data transmission and offers data storage and retransmission capabilities.
Specifications
| Wireless Transmission | |
|---|---|
| Technology | LoRaWAN® |
| Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 |
| Tx Power | 16 dBm (868 MHz)/22 dBm (915 MHz)/19 dBm (470 MHz) |
| Sensitivity | -137dBm @300bps |
| Mode | OTAA/ABP Class A |
| Sensors | |
| Temperature | |
| Range | -20°C to + 70°C |
| Accuracy | 0°C to + 70°C (+/- 0.3°C), -20°C to 0°C (+/- 0.6°C) |
| Resolution | 0.1°C |
| Humidity | |
| Range | 0% to 100% RH |
| Accuracy | 10% to 90% RH (± 3%), below 10% and above 90% RH (± 5%) |
| Resolution | 0.5% RH |
| Carbon Dioxide (CO) | |
| Range | 400 to 5000 ppm |
| Accuracy | ± (30 ppm + 3 % of reading) |
| Resolution | 1 ppm |
| Display & Configuration | |
| Display | AM103: 2.13-inch Dark & Light E-Ink Screen AM103L: Not Support |
| Button | 1 × Power Button + 1 × Reset Button |
| LED | 1 × Traffic Light Status Indicator + 1 × Buzzer |
| Configuration | Mobile App via NFC |
| Physical Characteristics | |
| Power Supply | 2 × 2700 mAh ER14505 Li-SOCl Replaceable Batteries |
| Battery Life (10 min interval) | AM103: Around 3 Years AM103L: Around 4 Years |
| Operating Temperature | -20°C to +60°C (E-Ink Screen: 0°C - 40°C) |
| Relative Humidity | 0% to 95% (non-condensing) |
| Ingress Protection | IP30 |
| Dimension | 68 × 65 × 20.5 mm (2.68 × 2.56 × 0.81 in) |
| Installation | Wall Mounting |
